XT-605D Fully Automatic Alpha Coil Winding Machine designed for coil alpha method winding, It is applied in wireless chargers, transformer coils, etc. This equipment is a new type of machine specially designed by our company for the production of Alpha mode coils. The main coils produced are wireless charging and transmitting coils and other similar products.

This winding machine adopts an advanced CNC motion controller. The motion controller can perform high-precision linear positioning, accurate arc insertion positioning, and long service life. Special coils can be designed and wound according to customer needs.

Alpha coil winding machine basic introduction

This machine is a new type of winding machine designed for the wireless charging transmitter coil. It can be used to wind the outer winding of related materials such as wire-wrapped wire,multi-strand wire and single wire. Adding a robot can cut the line, complete the line, and solder in the back section, and it can work with the assembly line. The fuselage is poured into the cold iron, stable and generous; the control system adopts the touch screen interface, the operation is simple and easy to learn; the mechanical structure design is reasonable, the materials used are processed by specialization process; the mechanical movement part adopts imported servo motor and high precision ball screw, rotating Partially imported bearings ensure high efficiency and high precision.

Application areas

Wireless charging transmitter coil, transformer coil, etc.

Product Parameters

Basic information about XINGTE

Experience
XINGTE was established in 2007, with more than 17 years R & D experience in the coil winding area

Plant Size
XINGTE is headquartered in Shenzhen, with a factory area of more than 30,000 square meters, which can ensure our Strong productivity

Service
XINGTE has more than 230 technical service and after-sales staff, worldwide service points worry-free after-sales service

Patents & certificates

Patents & certificates:
XINGTE obtained 120+ Patents and related certificates

Production Capacity
XINGTE has more than 600 experienced employees, which can guarantee our Production capacity and fast delivery

Technology

XINGTE has more than 130 experienced engineers, which can ensure our strong R & D ability, also can guarantee our customization capability


XINGTE PRODUCTION LINE

1, Motor stator, rotor, and other related coil winding machine

2, Transformer-related product coil winding machine

3, voice coil-related product winding machine

4, inductor coil winding machine and

5, customized fully automatic line for the motor, speaker, transformer production line



Our factory

Machines


Special-Shaped Coils ​ finished product




Delivery

Shenzhen Xingte Technology Co., Ltd. was founded in 2011. It is a national high-tech enterprise with more than 1.000 employees and a factory area of 30,000 square meters. Xingte specializes in the research and development, production, sales, and technical services of fully automatic winding machines and winding systems. Xingte currently has an R&D team of more than 260 people and a high-quality after-sales service team of more than 400 people.

Xingte obtained more than 200 invention patents, utility model patents, software copyrights, and other certificates like CE, KC, etc. Xingte is a member unit of the Shenzhen Camera Industry Association and a governing unit of the Robot Intelligent Equipment Industry Association. The company has an independent machining center, complete production supporting equipment, and controllable product manufacturing costs and quality. The entire product production process adopts information management. Effectively manage production factors and implement the 6S (sorting, reorganizing, sweeping, cleaning, quality, and safety) on-site management concept within the company. Continuously improved the company's quality management to enhance customer satisfaction, and obtained ISO9001 quality management system certification.

The company's products are mainly used in mobile phones, computers, headphones, wireless charging, photovoltaics, new energy vehicles, electronic components, and other fields. Specializing in providing various types of speaker voice coil winding machines, motor winding machines, wireless charging coil winding machines, toroidal magnetic winding machines, new energy intelligent equipment, air core coil winding machines, transformer winding machines, and the middle and rear sections of magnetic rings Assembly lines and other production equipment as well as fully automatic speaker assembly equipment!

Our products are exported to all over the world such as Southeast Asia and European and American countries, South Korea, Singapore, Vietnam, Philippines, Turkey, etc. It has widely served well-known domestic and world brands such as Huawei, Apple, Samsung, and Xiaomi, and has been unanimously recognized by customers.

Our Vision: To be the global leader in coil winding and related equipment manufacturing

Our Mission: Create value and a better life for customers

Our values:Customer-centric: win-win cooperation, faster and better, Staff-oriented: emphasizing both ability and integrity and continuous optimization
