Product Description:

The automatic coil winding machine is a type of automated equipment used to precisely wind enameled wire into inductor coils. This advanced machine is widely utilized in a variety of industries such as motor manufacturing, electroacoustics, and transformers. It is also essential for other industries that require inductive coils including electric motors, fluorescent lamp ballasts, and various electronic devices.
The primary function of the automatic coil winding machine is to accurately wrap enameled wire onto a pre-set frame according to specific specifications and parameters. This process involves automatic wiring, wrapping, breaking, twisting, and loading and unloading. The operator only needs to ensure sufficient materials are available and replace them in a timely manner to ensure continuous production. This equipment drastically improves production efficiency, reduces labor costs, and guarantees consistent and high-quality product output.
In addition to its main function, the automatic coil winding machine also offers various settings and debugging functions. This includes the ability to adjust winding position, enameled wire specifications, and winding width to achieve the best possible winding effect for different products and process requirements.
Overall, the automatic coil winding machine is a highly efficient, accurate, and reliable piece of automated production equipment. It plays a critical role in the manufacturing of inductor coils and contributes to the progress and development of modern industrial production techniques.

Product Features:

The Precision ball screw used in this product ensures accurate wire arrangement, resulting in precise, tight, and consistent winding.
With four work stations operating simultaneously, this product offers automatic wire arrangement, slot changing, winding, and clipping and cutting of thread ends. This saves time and improves efficiency.
The advanced system in this product is equipped with an AC servo motor drive system for precise positioning, ensuring high-quality results.
Featuring a 10-inch HMI, this product offers intuitive and simple operation. By editing programs in a dialogue mode, it is easy to use and offers a user-friendly experience.
In order to prevent unauthorized changes to the program, this product also offers hierarchical management and password storage functions. This ensures only authorized personnel can make changes.
The simple structure of this product makes it easy to control and maintain, providing convenience to the user.

Technical Parameters:

• Stator automatic winding machine
• Automatic coil winding
• Auto coil winding machine

The machine pictures

Applications:

The stator winding machines are essential components in various industries, including:

The stator winding machines are used to produce motors for model aircrafts. These motors are crucial in providing power and control for the aircraft's movement.

Stator winding machines are used to manufacture motors for fascia guns, a type of handheld massaging device used for muscle relaxation and pain relief. These motors provide the necessary vibration for the gun to function effectively.

For the production of balancing cars, stator winding machines are used to create the motors that control the motion and balance of the car. These machines play a crucial role in ensuring the safety and stability of balancing cars.

Electric scooters are becoming more popular as a convenient mode of transportation. Stator winding machines are used to produce the motors that power these scooters.

With the rise of electric vehicles, stator winding machines are in high demand for producing the motors that drive these cars. These machines play an essential role in promoting sustainable transportation.

Rotary transformers are used in various electronic and industrial applications to transfer electrical energy between two circuits. Stator winding machines are essential in producing the stator windings for these transformers.

The motors used in fans and cooling systems are created by stator winding machines. These motors are crucial for maintaining proper air circulation and temperature control in various settings, such as homes, offices, and industrial facilities.

Stator winding machines are used to produce the motors for twist cars, a type of children's toy vehicle that can pivot and spin. These motors provide the twisting motion and control for the cars.

Customization:

XINGTE

XT-04F

CHINA

CE, IOS9001, KC, ISO45001, ISO24001

1

Negotiate

Wooden case

15-35 days

LC, T/T

1,000 PCS/MONTH

5-50mm

450kgs

Motion Controller

Touch Screen

1-999 Adjustable

automatic fan coil winding machine, coil winding machine automatic, stator automatic winding machine

FAQ:

• Q: What is the brand name of this product?
• A: The brand name of this product is XINGTE.
• Q: What is the model number of this product?
• A: The model number of this product is XT-04F.
• Q: Where is this product manufactured?
• A: This product is manufactured in China.
• Q: What certifications does this product have?
• A: This product has CE, IOS9001, KC, ISO45001, and ISO24001 certifications.
• Q: What is the minimum order quantity for this product?
• A: The minimum order quantity for this product is 1.
• Q: Can the price of this product be negotiated?
• A: Yes, the price of this product can be negotiated.
• Q: How is this product packaged?
• A: This product is packaged in a wooden case.
• Q: How long does it take for this product to be delivered?
• A: It takes 15-35 days for this product to be delivered.
• Q: What are the payment terms for this product?
• A: The payment terms for this product are LC and T/T.
• Q: What is the supply ability of this product?
• A: The supply ability of this product is 1,000PCS per month.
