Product Description:
XT-BL06 Automatic Motor Winding Machine
The XT-BL06 Automatic Motor Winding Machine is a vital piece of
equipment utilized in the production and repair of electric motors.
This cutting-edge machine is instrumental in achieving a high level
of expertise in creating automatic systems for the manufacture of
wound components for the motor market.
With its advanced features, the XT-BL06 offers numerous advantages
as compared to traditional manual winding techniques. It
significantly improves the efficiency and accuracy of motor winding
processes, resulting in higher quality products. Additionally, the
machine provides increased precision and accuracy, reduces winding
time with faster speeds, and lowers production costs, making it an
ideal choice for producing high-powered and high-performance
motors.
In summary, the XT-BL06 Automatic Motor Winding Machine is a
necessary tool for production and repair of electric motors,
offering efficient and precise coil winding for a wide range of
motor components. Its cutting-edge technology and reliable
performance make it a valuable asset for any motor manufacturing or
repair facility.
Product Features:
Our product boasts a combination of a cast iron body and a sturdy
sheet metal frame, ensuring stability and reliability.
We utilize a state-of-the-art motion controller that enables fast
response and high efficiency.
The six-station automatic simultaneous winding feature allows for
automatic cable arrangement, slot change, PN foot wrapping, and
clamping and trimming of thread ends.
With the use of a precision ball screw for wiring, our winding
process is precise, tight, and consistent.
This results in improved production efficiency, reduced wire
consumption, and enhanced product quality.
Our programmable English touch screen interface is user-friendly,
making operation effortless. It also has the ability to store
multiple sets of parameters at once.
For added convenience, we offer optional pneumatic scissors,
electronic tensioners, and servo tensioners. Our threaded nozzle
conveniently extends into the slot for winding.
The machine pictures
Technical Parameters:
| Product Name | Motor Winding Machine |
|---|
| Model | XT-BL06 |
|---|
| Winding Modes | Flyer Winding |
|---|
| Max Winding Speed | 6000 Rpm |
|---|
| Winding Accuracy | ±0.01mm |
|---|
| Yield Rate | ＞99% |
|---|
| Power Supply | 3 Phase 380v, 50/60Hz |
|---|
| Control System | PLC Touch Screen |
|---|
| Stator Diameter Range | 25-65mm |
|---|
| Operate Rate | ＞85% |
|---|
| G .W. | 650Kgs |
|---|
Applications:
Products Utilizing XT-BL06 Flyer Automatic Motor Winding Machine
Automobile Industry
The XT-BL06 Flyer Automatic Motor Winding Machine is an essential
tool used in the production of various components in the automotive
industry. Its advanced technology allows for precise winding of
motor coils used in windshield wipers, power windows, blowers,
radiator cooling fans, EPS, ABS/ESC systems, and more.
Household Electrical Appliances
The XT-BL06 Flyer Automatic Motor Winding Machine is also widely
used in the production of household electrical appliances. It is
capable of efficiently winding motors for vacuum cleaners, washing
machines, juicers, mixers, shavers, dryers, and other household
appliances.
Industrial and Medical Equipment
In addition to the automotive and household appliance industries,
the XT-BL06 Flyer Automatic Motor Winding Machine is also commonly
used in the production of industrial and medical equipment. Its
accuracy and reliability make it a valuable tool in winding motors
for power tools, robots, pumps, and other equipment.
Office Automation/Audio-Visual Equipment
The XT-BL06 Flyer Automatic Motor Winding Machine is an essential
asset in the production of office automation and audio-visual
equipment. Its precision winding capabilities are utilized in the
production of printers, copiers, faxes, HDDs, DVDs, CDs, and other
similar devices.
The pictures of the finished stator
Customization:
Motor Winding Machine Customization Service
Brand Name: XINGTE
Model Number: XT-BL06
Place of Origin: Shenzhen
Certification: CE, IOS9001, KC, ISO45001, ISO24001
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Wooden case
Delivery Time: 15-25 working days
Payment Terms: LC, T/T
Supply Ability: 1,500 PCS/MONTH
Max Winding Speed: 6,000 Rpm
Model: XT-BL06
G.W.: 650Kgs
Machine size: 1200(L) * 1610(W) * 1800(H) mm
Air Pressure: 0.4-0.6Mpa
This customized 6 station motor winding machine is designed and
manufactured by XINGTE in Shenzhen. With our certifications in CE,
IOS9001, KC, ISO45001, and ISO24001, you can trust the quality and
safety of our products. Our minimum order quantity is only 1
machine and we are open to negotiate the price. The packaging is
done in a sturdy wooden case for safe transportation. The delivery
time is 15-25 working days and we accept payment through LC or T/T.
Our supply ability is 1,500 PCS per month.
The XT-BL06 model is a high-speed motor winding machine with a
maximum winding speed of 6,000 Rpm. It can be used for winding DC
motors and is suitable for manufacturers in need of an automated
motor winding machine. This machine has a G.W. of 650Kgs and its
dimensions are 1200(L) * 1610(W) * 1800(H) mm. It requires an air
pressure of 0.4-0.6Mpa to operate efficiently.
Pictures of our factory
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is XINGTE.
- Q: What is the model number of this product?
- A: The model number of this product is XT-BL06.
- Q: Where is this product manufactured?
- A: This product is manufactured in Shenzhen, China.
- Q: What certifications does this product have?
- A: This product is certified by CE, IOS9001, KC, ISO45001, and
ISO24001.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 1 unit.
- Q: Is the price negotiable for this product?
- A: Yes, the price is negotiable for this product.
- Q: How is this product packaged?
- A: This product is packaged in a wooden case.
- Q: How long is the delivery time for this product?
- A: The delivery time for this product is 15-25 working days.
- Q: What are the payment terms for this product?
- A: The payment terms for this product are LC and T/T.
- Q: What is the supply ability for this product?
- A: The supply ability for this product is 500 units per month.
