High Precision Flyer Motor Winding Machine With Dual Work Station
Directly From China Factory
It is designed for motor stator and rotor high-speed coil winding
Customized Available, We can custom make the automatic Ceiling
motor Winding Machine According to your Stator & Rotor Diameter and
Height.
Product Features
◆ Two workstations can work at the same time, winding multiple
strands of copper wire, and the single strands of wire are arranged
closely
◆ Special stator core winding solutions can be customized as
non-standard, suitable for all types of externally wound stator
windings
◆ The modular design of the fixture makes it easier to change
models
◆ Multiple adjustable models, fast switching, high efficiency, and
fast production cycle
◆ Simple setting parameters.
◆ Stable performance and stable quality.
◆ Automatic winding, multi-wire diameter winding, automatic
indexing, automatic slot crossing.
◆ High production efficiency, and labor cost saving.
Application areas
Model aircraft motors, balancing car motors, scooter motors, new
energy vehicle motors, rotary transformers, fan stators, twist car
motors, cooling fan stators, plant protection machines, various
types of externally wound stators, etc.
Product parameters
| Model number: | XT-02F |
| Wire Diameter : | 0.1 ~ Ø1.6mm |
| Stator Outer diameter: | Max 140mm |
| Stator inner diameter: | 10mm |
| Stator stack thickness : | 150mm |
| Winding method: | flyer winding |
| Winding station: | 2 stations |
| Power: | 6.5KW |
| Power supply: | AC380V,50/60Hz |
| Air pressure: | > 0.5Mpa |
| Winding speed: | 2000Rpm |
| Machine dimension: | (L)850 *(W)650*(H)1600 mm |
| G. W: | 650KGS |
